Focal Chorus 705 Manual

This manual provides comprehensive information on the Focal Chorus 705 bookshelf speaker system‚ including setup‚ operation‚ troubleshooting‚ and maintenance. It covers features‚ specifications‚ and accessories‚ as well as warranty details and resources.

The manual is available in PDF format and can be downloaded for free. It includes user feedback and frequently asked questions to help you optimally use your product. This manual is available in English.

If you require additional support or have specific questions‚ you can contact Focal directly through their website or visit an authorized retailer.

Overview

The Focal Chorus 705 is a 2-way bookshelf speaker system designed for small to medium-sized rooms. It features a 14 cm poly-glass woofer and a TNV2 tweeter‚ delivering a clear and dynamic sound experience. The Chorus 705 is known for its rich midrange‚ responsive bass‚ and smooth treble‚ making it suitable for a wide range of musical genres and home theater applications.

The speaker is designed for a variety of mounting options‚ including the Chorus S 700 stand (sold separately). This stand is specifically designed to elevate the Chorus 705 and improve sound quality. The Chorus 705 is also compatible with subwoofers‚ allowing for an even more powerful and immersive audio experience.

The Focal Chorus 705 is a highly regarded speaker system known for its exceptional sound quality and value for money. It is a popular choice for audio enthusiasts seeking a balanced and engaging listening experience in a compact and stylish package.

Specifications

The Focal Chorus 705 boasts a range of specifications that contribute to its impressive sound performance. These specifications include⁚

• Type⁚ 2-way bookshelf speaker system
• Woofer⁚ 14 cm (5.5″) poly-glass cone
• Tweeter⁚ 25 mm (1″) TNV2 inverted dome
• Frequency Response⁚ 55 Hz ⸺ 28 kHz
• Sensitivity⁚ 88 dB (2.83V/1m)
• Impedance⁚ 8 ohms
• Power Handling⁚ 100 watts
• Dimensions (H x W x D)⁚ 330 x 200 x 260 mm (13″ x 8″ x 10.2″)
• Weight⁚ 6.5 kg (14.3 lbs)

These specifications highlight the Chorus 705’s ability to reproduce a wide frequency range with impressive clarity and detail. The speaker’s high sensitivity and moderate impedance ensure compatibility with a variety of amplifiers‚ while its power handling capabilities allow for dynamic and impactful sound reproduction.

Features

The Focal Chorus 705 bookshelf speaker system incorporates a range of features designed to deliver exceptional audio performance and versatility. These features include⁚

• Poly-glass woofer⁚ The 14 cm (5.5″) poly-glass woofer offers a combination of rigidity and lightness‚ resulting in precise and dynamic bass reproduction. The poly-glass construction minimizes unwanted resonance and distortion‚ ensuring accurate low-frequency response.
• TNV2 inverted dome tweeter⁚ The 25 mm (1″) TNV2 inverted dome tweeter delivers clear and detailed high frequencies with a smooth and natural sound. Its innovative design minimizes diffraction and improves dispersion‚ resulting in a wide and accurate soundstage.
• High-quality crossover⁚ The Chorus 705 features a carefully engineered crossover network that ensures seamless integration between the woofer and tweeter‚ resulting in a balanced and coherent sound signature.
• Compact and stylish design⁚ The speaker’s compact size and sleek design make it suitable for a variety of room setups‚ while its elegant aesthetics complement any interior décor.

These features‚ combined with the speaker’s well-balanced specifications‚ contribute to the Chorus 705’s ability to deliver a rich and immersive listening experience‚ faithfully reproducing a wide range of musical genres and audio content.

Setup and Installation

Setting up the Focal Chorus 705 bookshelf speaker system is a straightforward process. Follow these steps for optimal performance⁚

1. Placement⁚ Position the speakers on stable surfaces‚ ensuring they are level. Experiment with different distances from the walls and listening position to fine-tune the soundstage and imaging.
2. Speaker Connections⁚ Connect the speakers to your amplifier or receiver using high-quality speaker cables. Ensure the positive (+) and negative (-) terminals are correctly aligned. Refer to your amplifier or receiver’s manual for specific instructions.
3. Amplifier Settings⁚ Adjust the amplifier’s volume and tone controls to your liking. Use the speaker level controls on your amplifier or receiver to balance the volume between the speakers.
4. Optional Accessories⁚ The Chorus 705 can be paired with the Focal Chorus S 700 stand (sold separately) to enhance its performance and aesthetics. The stand is designed to elevate the speaker and improve its sound dispersion.
5. Break-in Period⁚ Allow the speakers to run for several hours or days to allow the drivers to break in and reach their optimal performance levels.

With proper setup and placement‚ the Focal Chorus 705 speakers will deliver exceptional audio quality and a satisfying listening experience.

Operation

The Focal Chorus 705 speakers are designed for easy operation and integration into your audio system. Here’s a guide to using them effectively⁚

1. Volume Control⁚ Adjust the volume level using the amplifier or receiver’s volume knob. Gradually increase the volume to avoid clipping or distortion.
2. Tone Controls⁚ Experiment with the tone controls on your amplifier or receiver to fine-tune the sound to your preference. Adjust the bass and treble levels to achieve the desired balance and clarity.
3. Source Selection⁚ Choose your desired audio source (CD player‚ turntable‚ TV‚ etc.) using the amplifier or receiver’s input selector. Ensure the source is properly connected and turned on.
4. Speaker Level Controls⁚ Use the speaker level controls on your amplifier or receiver to balance the volume between the speakers‚ ensuring equal output from both channels.
5. Crossover Settings⁚ If your amplifier or receiver has crossover settings‚ adjust them to match the frequency response of the Chorus 705 speakers for optimal performance.

Remember to always handle the speakers with care and avoid exposing them to excessive moisture‚ dust‚ or extreme temperatures. For optimal longevity‚ refer to the maintenance section for cleaning and care instructions;

Troubleshooting

While the Focal Chorus 705 speakers are designed for reliable performance‚ issues can arise. Here’s a guide to troubleshooting common problems⁚

• No Sound⁚ Ensure the speakers are properly connected to the amplifier or receiver‚ the volume is turned up‚ and the source device is selected correctly. Check for any loose connections or damaged cables.
• Distorted Sound⁚ Reduce the volume level to prevent clipping or overdriving the amplifier or receiver. If the distortion persists‚ check for speaker placement issues‚ such as being too close to a wall or other objects.
• Weak Bass⁚ Ensure the bass level on your amplifier or receiver is properly adjusted. Consider adding a subwoofer to enhance the low frequencies if the bass is still lacking.
• One Speaker Not Working⁚ Check the speaker connections for loose or faulty wires. Verify that the speaker is properly selected on your amplifier or receiver. If the issue persists‚ the speaker itself may require repair.
• Buzzing or Humming⁚ Check for grounding issues‚ such as a loose connection or damaged ground wire. If the issue persists‚ consult a qualified technician for repair.

If you encounter any persistent problems‚ refer to the warranty information in this manual or contact Focal directly for support.

Maintenance

Proper maintenance ensures your Focal Chorus 705 speakers deliver optimal performance for years to come. Follow these guidelines⁚

• Dust Removal⁚ Regularly clean the speaker cabinets and drivers using a soft‚ dry cloth. Avoid using harsh chemicals or abrasive materials that could damage the finish.
• Driver Protection⁚ When not in use‚ cover the speakers with dust covers to protect the drivers from dust and debris. Ensure the covers are breathable to prevent moisture buildup.
• Speaker Placement⁚ Avoid placing the speakers in direct sunlight or near sources of heat‚ as this can degrade the materials over time. Ensure adequate ventilation around the speakers to prevent overheating.
• Humidity Control⁚ Maintain a moderate humidity level in the listening environment to prevent damage to the speaker components. Excessive humidity can lead to mold and mildew growth‚ while extremely dry air can cause static electricity.
• Professional Service⁚ If you encounter any issues with the speakers‚ such as damaged drivers or internal components‚ consult a qualified technician for repair. Attempting to repair the speakers yourself can void the warranty and potentially damage the speakers further.

By following these simple maintenance tips‚ you can prolong the life of your Focal Chorus 705 speakers and enjoy their exceptional sound quality for years to come.

Accessories

Enhance your Focal Chorus 705 speaker experience with a range of optional accessories designed to optimize performance and aesthetics.

• Speaker Stands⁚ The Focal Chorus S 700 stand‚ specifically designed for the Chorus 705 bookshelf speaker‚ elevates the speakers to an optimal listening height‚ enhancing the soundstage and imaging. It is sold separately and provides a stylish and functional platform for your speakers.
• Speaker Grilles⁚ The Chorus 705 speakers come with detachable grilles to protect the drivers and complement the overall aesthetic. These grilles can be removed for a more open and detailed sound‚ depending on personal preference.
• Cable Connectors⁚ To ensure optimal signal transfer and sound quality‚ consider high-quality speaker cables and banana plugs. These accessories offer a secure connection and minimize signal loss‚ enhancing the overall audio performance.
• Subwoofer Integration⁚ To extend the low-frequency response and create a truly immersive audio experience‚ consider pairing the Chorus 705 speakers with a compatible subwoofer. This will provide a more impactful and powerful bass response‚ ideal for movies and music genres with deep bass frequencies.

These accessories are not mandatory but can significantly enhance your listening experience. Choose the accessories that best suit your needs and preferences to create a truly personalized audio setup.

Warranty

Focal offers a comprehensive warranty program to ensure the quality and longevity of their products. The specific warranty terms and conditions may vary depending on the region of purchase and the model of the speaker.

To access the warranty information for your Focal Chorus 705 speakers‚ you should refer to the user manual or contact Focal directly through their website or authorized retailers. The warranty typically covers defects in materials and workmanship under normal use. It may also include coverage for certain components‚ such as the drivers‚ for a specific period of time.

It’s important to note that the warranty may not cover damage caused by misuse‚ neglect‚ accidents‚ or unauthorized repairs. To ensure your warranty remains valid‚ it is advisable to keep your original purchase receipt‚ as this will serve as proof of purchase. For any warranty-related inquiries‚ you can contact Focal customer support for guidance and assistance.

Resources

For further information and support related to the Focal Chorus 705 speakers‚ a variety of resources are available to you. Focal’s official website provides a comprehensive library of product information‚ including user manuals‚ specifications‚ and FAQs. The website also features a dedicated customer support section where you can find answers to common questions and submit inquiries.

Additionally‚ online forums and communities dedicated to audiophiles and Focal enthusiasts offer a platform to connect with other users‚ share experiences‚ and seek advice. These online resources can provide valuable insights into the Chorus 705 speakers‚ including setup tips‚ troubleshooting guides‚ and reviews from other users.

You can also consult authorized Focal retailers for assistance‚ as they often have knowledgeable staff who can provide guidance on product usage‚ compatibility‚ and potential issues. By leveraging these resources‚ you can enhance your understanding of the Focal Chorus 705 speakers and ensure you get the most out of your audio experience.
